Medical External Power Supply UE05LCP-SPA
Home Wall Plug Medical External Power Adapter UE05LCP-SPA Interchangeable Class II AC Plug 5V Wall Plug Hospital Grade External Power Adapter 5 W 90 ~
Meets communication and medical safety certification
2 MOPP isolation protection
Meets medical equipment BF(∧) level
Leakage current ≤ 10μA
Energy efficiency DOE efficiency level 6
CoC V5 Tier 2(2016)
Standby power consumption ≤ 0.075W
Working altitude 5000 meters
4V to 24V output, up to 12W
Equipped with a variety of interchangeable AC pins
With constant current and conversion functions, it can be used as a battery charger
Includes short circuit protection, overvoltage protection, and overload protection
The UES12LCP-SPA is a versatile 12W AC to DC wall plug power supply designed for medical applications. With a universal 90- 264VAC input, it supports 4V to 24V, such as 5V, 9V, 12V,16v,19v,20v, and 24v. outputs and delivers up to 2A. Certified to IEC 60601-1 and IEC 62368-1, ISO 13485 compliant, it ensures 2 x MOPP isolation, ≤100µA leakage current, and DOE Level VI efficiency with ≤0.1W standby power. Compact, with interchangeable AC blades and operating up to 5,000m altitude, it’s ideal for portable medical devices and electronics, providing safe, efficient, and reliable power globally. Apply to blood pressure monitor, pulse oximeter, portable nebulizer, portable dental cleaning device, LED therapy mask, and TENS electrical stimulator.
Safety Standards – IEC60601,ES60601,EN60601
Safety Approvals – S-MARK, BIS, CB, CCC, CE, cULus, FCC, KC, NRTL, PSB, PSE, RCM, TUV-GS, TUV-Mark
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES12LCP-SPA | 10.0 | 90-264 | 4.0-5.0 | 0.01-2.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 5.1-6.0 | 0.01-2.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 6.1-7.0 | 0.01-1.71 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 7.1-8.0 | 0.01-1.50 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 8.1-9.0 | 0.01-1.33 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 9.1-10.0 | 0.01-1.20 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.99 | 90-264 | 10.1-11.0 | 0.01-1.09 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 11.1-12.0 | 0.01-1.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.22 | 90-264 | 12.1-13.0 | 0.01-0.94 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.04 | 90-264 | 13.1-14.0 | 0.01-0.86 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 14.1-15.0 | 0.01-0.80 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 15.1-16.0 | 0.01-0.75 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.07 | 90-264 | 16.1-17.0 | 0.01-0.71 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.06 | 90-264 | 17.1-18.0 | 0.01-0.67 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 18.1-19.0 | 0.01-0.63 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 19.1-20.0 | 0.01-0.60 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 20.1-21.0 | 0.01-0.57 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.1 | 90-264 | 21.1-22.0 | 0.01-0.55 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.96 | 90-264 | 22.1-23.0 | 0.01-0.52 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 23.1-24.0 | 0.01-0.50 | -5~+45 | CE, UL/cUL,TUV |
It is commonly used in portable monitors, nebulizers, blood pressure meters, pulse oximeters, and small IVD analyzers.
Yes, it is ideal for home medical devices due to its compact size, low noise, and stable output.
Yes, the adapter supports customized output from 4V to 24V to meet various device requirements.
Yes, models can be designed to meet IEC 60601-1 and other medical safety certifications.
Compact size, wide voltage range, high efficiency, low ripple, and optional medical-grade safety compliance.
Yes, it complies with DOE Level VI and EU CoC Tier 2 efficiency standards.
Yes, it's suitable for small dental tools like curing lights and certified beauty medical instruments.
Depending on the output voltage, the current ranges from 0.5A to 3A.
Yes, it's suitable for low-power battery charging applications with proper voltage regulation.
Multiple DC plug options are available, including standard barrel types and custom connectors.
