Medical External Power Supply UES18LCP4-SPA
Home Wall Plug Medical External Power Supply UES18LCP4-SPA 18W Switching Power Supply Home Healthcare Medical Wall Plug AC External Power Adapter 18 W 90~ 264
24W
90~ 264 Vac input
6~52 Vdc output options
0°C to +45°C temperature range
No-load power consumption < 0.075 W
2 MOPP input to output isolation
The UES24LU2-SPA series is a 24W medical power adapter 12V wall plug AC to DC external switching power supply developed for the USA market, designed for home healthcare applications. It offers multiple output options, including 6.1V, 12V, 24V, 36V, 48V, and 52V, among other voltages (coming with a universal input of 90~264VAC), to cater to various medical devices. This power supply feature adheres to the stringent safety standards of IEC 60601-1 3.1 Edition for 2 x MOPP applications, as well as the 4th Edition EMC requirements, ensuring class II operation. Featuring compact size, Level VI efficiency, and different construction, these medical power supplies are a continuation of initiatives to provide customers with global solutions for dental LED curing light, portable electric dental bed, laser hair removal device, medical syringe pump, portable suction device, portable CPAP humidifier, this power supply provides a wide selection of AC plugs and DC connectors to ensure compatibility with your specific devices and equipment.
Safety Standards – IEC60601,EN60601,UL60601
Safety Approvals – UL/cUL/TUV/CB
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES24LU2-SPA | 21.0 | 90-264 | 6.1-7.0 | 0.01-3.00 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 21.0 | 90-264 | 7.1-8.0 | 0.01-2.62 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 21.0 | 90-264 | 8.1-9.0 | 0.01-2.33 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 21.0 | 90-264 | 9.1-10.0 | 0.01-2.10 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 10.1-11.0 | 0.01-2.18 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 11.1-12.0 | 0.01-2.00 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 12.1-13.0 | 0.01-1.84 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 13.1-14.0 | 0.01-1.71 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 14.1-15.0 | 0.01-1.60 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 15.1-16.0 | 0.01-1.50 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 16.1-17.0 | 0.01-1.41 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 17.1-18.0 | 0.01-1.33 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 18.1-19.0 | 0.01-1.26 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 19.1-20.0 | 0.01-1.20 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 20.1-21.0 | 0.01-1.14 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 21.1-22.0 | 0.01-1.09 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 22.0-23.0 | 0.01-1.04 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 23.1-24.0 | 0.01-1.00 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 45.1-46.0 | 0.01-0.52 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 46.1-47.0 | 0.01-0.51 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 47.1-48.0 | 0.01-0.50 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 48.1-49.0 | 0.01-0.49 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 49.1-50.0 | 0.01-0.48 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 50.1-51.0 | 0.01-0.47 | 0 ~ +45 | CB, UL/cUL,TUV |
| UES24LU2-SPA | 24.0 | 90-264 | 51.1-52.0 | 0.01-0.46 | 0 ~ +45 | CB, UL/cUL,TUV |
Yes, it is suitable for various low-power dental devices and control modules.
It supports LED curing lights, intraoral cameras, control panels, and motor drivers.
Yes, many charging bases and LED control units operate at 12V or 24V.
Yes, it provides stable voltage for image processing and display units.
Yes, it complies with IEC 60601-1 and 60601-1-2 medical safety and EMC standards.
Yes, if the motor control system is within 24W and uses 12–48V DC.
Yes, models with adjustable output from 6V to 52V are available.
Yes, it is designed for continuous, stable operation in medical-grade environments.
Yes, it is ideal for mobile or compact dental systems with lower power needs.
Standard DC barrel jacks or customized connectors are optional.
