Medical AC-DC Power Supply Modules UES30-SPA
30 W
85 ~ 265 Vac input (wide)
-25°C to +65°C temperature range
2 MOPP input to output isolation
DOE Efficiency Level VI
Leakage current <100μA
Applications: Infusion pump, oxygen concentrator
DESCRIPTION
The UES30-SPA is an AC-DC medical power supply module that offers a hospital-grade switching power adapter, designed for home healthcare applications. It offers multiple output options, including 5V, 9V, 12V, 15V, 18V, and 24V, among other voltages (coming with a universal input of 85~265VAC). It delivers a regulated 24V output at 1.25A. It complies with IEC 60601-1 medical safety standards and provides 2 x MOPP isolation protection and ≤100μA touch leakage current, making it safe for patient-connected devices. Adapter for an Infusion pump, oxygen concentrator. This power supply provides a wide selection of AC plugs and DC connectors to ensure compatibility with your specific devices and equipment.
SAFETY & COMPLIANCE
Safety Standards – IEC60601,UL62368
Safety Approvals – CB, UL
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES30-XXXYYYSPA | 30.0 | 85-265 | 5.0 | 0.01-6.00 | -25~+65 | CB,UL |
| UES30-XXXYYYSPA | 30.0 | 85-265 | 9.0 | 0.01-3.33 | -25~+65 | CB,UL |
| UES30-XXXYYYSPA | 30.0 | 85-265 | 12.0 | 0.01-2.50 | -25~+65 | CB,UL |
| UES30-XXXYYYSPA | 30.0 | 85-265 | 15.0 | 0.01-2.00 | -25~+65 | CB,UL |
| UES30-XXXYYYSPA | 30.0 | 85-265 | 18.0 | 0.01-1.66 | -25~+65 | CB,UL |
| UES30-XXXYYYSPA | 30.0 | 85-265 | 24.0 | 0.01-1.25 | -25~+65 | CB,UL |
RELATED APPLICATIONS
POPULAR QUESTIONS
It provides a regulated 24V DC output at up to 1.25A, with a maximum output power of 30W.
Yes, it complies with IEC 60601-1 medical safety standards and features 2 x MOPP insulation for patient safety.
The touch leakage current is ≤100μA, making it suitable for patient-contact medical devices.
Yes, the UES30-SPA operates reliably at altitudes up to 5000 meters.
It’s ideal for dental curing lights, portable ultrasound probes, rehabilitation stimulators, and small diagnostic analyzers.
It includes overload, overvoltage, and short-circuit protections to ensure safe and stable operation.
Standby power consumption is ≤0.1W, meeting DOE Efficiency Level VI requirements.
Yes, Quankang offers flexible customization options for DC connectors to match your device requirements.
The unit measures approximately 70mm x 48mm x 23.5mm and weighs about 170g.
While it’s physically possible, it’s recommended to power off devices before connecting/disconnecting to avoid electrical surges.
