Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP
Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP Home Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP 48Vdc 2A open frame power supply
12 W
90~ 264 Vac input
4.0 ~ 24 Vdc output options
-15°C to +45°C temperature range
No-load power consumption < 0.075 W
2 MOPP input to output isolation
interchangable AC pins
The UES12LCP-SPA series is a 12W medical wall plug 12V switching AC DC power supply with interchangeable AC pins, designed for home healthcare applications. It offers multiple output options, including 5V, 9V, 12V, and 24V, among other voltages (coming with a universal input of 90~264VAC), to cater to various medical devices. This power supply feature adheres to the stringent safety standards of IEC 60601-1 3.1 Edition for 2 x MOPP applications, as well as the 4th Edition EMC requirements, ensuring class II operation. Featuring compact size, Level VI efficiency, and different construction, these medical power supplies are a continuation of initiatives to provide customers with global solutions for medical magnifying glass lamp, fetal heart rate monitor, electronic blood pressure monitor, desktop type, medical label printer, body temperature recorder, cholesterol analyzer, this power supply provides a wide selection of AC plugs and DC connectors to ensure compatibility with your specific devices and equipment.
Safety Standards – IEC60601,EN60601,UL60601
Safety Approvals – CE, UL/cUL,TUV
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES12LCP-SPA | 10.0 | 90-264 | 4.0-5.0 | 0.01-2.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 5.1-6.0 | 0.01-2.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 6.1-7.0 | 0.01-1.71 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 7.1-8.0 | 0.01-1.50 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 8.1-9.0 | 0.01-1.33 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 9.1-10.0 | 0.01-1.20 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.99 | 90-264 | 10.1-11.0 | 0.01-1.09 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 11.1-12.0 | 0.01-1.00 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.22 | 90-264 | 12.1-13.0 | 0.01-0.94 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.04 | 90-264 | 13.1-14.0 | 0.01-0.86 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 14.1-15.0 | 0.01-0.80 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 15.1-16.0 | 0.01-0.75 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.07 | 90-264 | 16.1-17.0 | 0.01-0.71 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.06 | 90-264 | 17.1-18.0 | 0.01-0.67 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 18.1-19.0 | 0.01-0.63 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 19.1-20.0 | 0.01-0.60 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.97 | 90-264 | 20.1-21.0 | 0.01-0.57 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.1 | 90-264 | 21.1-22.0 | 0.01-0.55 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 11.96 | 90-264 | 22.1-23.0 | 0.01-0.52 | -5~+45 | CE, UL/cUL,TUV |
| UES12LCP-SPA | 12.0 | 90-264 | 23.1-24.0 | 0.01-0.50 | -5~+45 | CE, UL/cUL,TUV |
This adapter is suitable for low-power medical devices such as blood pressure monitors, glucose meters, fetal dopplers, and pulse oximeters.
Yes, it supports portable and desktop diagnostic tools requiring 5V, 9V, or 12V power inputs.
Absolutely. It can power low-voltage LED exam lights or magnifier lamps typically running on 12V.
Yes, devices like Wi-Fi or Bluetooth gateways and data receivers often use 5V–9V, well within its range.
Yes. Charging bases for hearing aids, therapy gloves, and similar wearable systems frequently operate at 5V or 9V.
Yes, it can supply power to digital pipettes, control modules, and sample mixers requiring 9V, 12V, or even 24V.
Yes, compact data collection and labeling devices usually operate within 5V–12V power ranges.
Common outputs include 5V, 6V, 9V, 12V, 15V, and 24V. Custom voltage settings are also possible.
Medical-grade versions comply with IEC 60601-1 safety and IEC 60601-1-2 EMC standards.
Options include DC barrel plug, USB-A, USB-C, and custom connectors upon request.
