ITE Power Adapter UES24W6-SPAZ
Home ite-external-power-adapter ITE Adapter UE24D1-SPAZ ITE Adapter UES24W6-SPAZ 24w wall plug types external switching power supply AC input voltage 90- 264VAC Covers short circuit protection,
AC input voltage 90- 264VAC
Covers short circuit protection, overcurrent protection, overvoltage protection
Meets 4kV surge immunity level
Meets level 5 energy efficiency
The UE18L-SPAC is an 18W AC to DC wall plug external power adapter delivering regulated 12V output. With CE certification and a compact, lightweight design, this universal power supply supports a wide 90–264VAC input range for stable operation in global applications.
Designed for reliability and energy-efficient performance, it ensures consistent power delivery for Wi-Fi routers, small network switches, mini desktop fans, LED strips and controllers, active speakers, and barcode scanners.
This robust adapter provides a cost-effective external power solution suitable for OEM projects, custom power supply deployments, and diverse low-power ITE devices, offering engineers durable, energy-saving, and flexible operation in indoor networking and IoT setups.
Safety Standards – GB4943, EN62368,
Safety Approvals – CCC ,CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UE18L-SPAC | 18.0 | 90-264 | 12.0 | 0.01-1.50 | -5~+45 | CCC |
UE18L-SPAC is a compact ITE power adapter for Wi-Fi routers, small network switches, LED strips and controllers, mini desktop fans, active speakers, barcode scanners, and other low-power indoor ITE devices that require stable regulated 12VDC output for networking and IoT applications.
Any 12V device that draws up to 1.5A, such as cameras, routers, LED lights, or small embedded systems.
Yes, it can power up to 18W worth of 12V LED strips. Ensure the total wattage of your LED strip does not exceed the adapter’s capacity.
Yes. It is designed for long-term, stable performance as long as it operates within its rated specifications and has adequate airflow.
It includes over-voltage protection (OVP), over-current protection (OCP), short-circuit protection (SCP), and thermal protection.
Yes. It accepts 100–240V AC input (50/60Hz), suitable for global use with the correct plug type.
The standard output connector is a 5.5mm x 2.1mm DC barrel plug, but this can be customized to match your device.
Most ITE power adapters comply with UL, CE, FCC, RoHS, and energy efficiency standards such as DOE Level VI or ErP.
Not directly. It can supply power to a battery charging circuit, but it is not a dedicated battery charger with CC/CV control.
ITE stands for Information Technology Equipment, which means the adapter is designed and certified for devices like routers, modems, and embedded systems.
Yes. It provides regulated 12V DC output with low ripple and noise, making it safe for sensitive electronic devices.
