Universal 5V Medical Power Supply UE05LC3-SPA Series
5 W 5-6V
90~ 264 Vac input
5 ~ 24 Vdc output options
0°C to +45°C temperature range
No-load power consumption < 0.075 W
2 MOPP input to output isolation
Application places: low-frequency electrotherapy devices/ portable nebulizer/ sleep monitor/ dental lighting equipment/ hearing aid/ pulse oximeter
DESCRIPTION
The UE05LC3-SPA series is a 5V 5W AC-DC wall plug medical external power supply, as well as a USB type AC to DC converter, designed for home healthcare applications. It offers multiple output options, including 5V and 6V, among other voltages (coming with a universal input of 90~264VAC), to cater to various medical devices. This power supply feature adheres to the stringent safety standards of IEC 60601-1 3.1 Edition for 2 x MOPP applications and the 4th Edition EMC requirements, ensuring class II operation. Small volume, Light weight, High efficiency. These medical power supplies can be applied in low-frequency electrotherapy devices, portable nebulizer, sleep monitor, dental lighting equipment, hearing aid, and pulse oximeter. This power supply provides a wide selection of AC plugs and DC connectors to ensure compatibility with your specific devices and equipment.
SAFETY & COMPLIANCE
Safety Standards – IEC60601,EN60601
Safety Approvals – CB, NRTL, TUV-Mark
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UE05LZ2-XXXYYYSPA | 5.0 | 90-264 | 5.0 | 0.01-1.00 | 0 ~ +45 | CE, NRTL,TUV |
| UE05LZ2-XXXYYYSPA | 4.8 | 90-264 | 6.0 | 0.01-0.80 | 0 ~ +45 | CE, NRTL,TUV |
| UE05LC3-XXXYYYSPA | 5.0 | 90-264 | 5.0 | 0.01-1.00 | 0 ~ +45 | CE, NRTL,TUV |
| UE05LC3-XXXYYYSPA | 4.8 | 90-264 | 6.0 | 0.01-0.80 | 0 ~ +45 | CE, NRTL,TUV |
RELATED APPLICATIONS
POPULAR QUESTIONS
Suitable for low-power devices such as blood pressure monitors, blood glucose meters, pulse oximeters, portable nebulizers, sleep monitors, etc.
Adapters that comply with IEC 60601-1 and 2xMOPP standards are safe, have low leakage current, and are suitable for surface contact devices.
Check whether the voltage (5V or 6V), current (≤1A), polarity, and DC plug required by the device match.
Must comply with IEC 60601-1 (safety), EN55011 (electromagnetic compatibility), and DoE VI (energy efficiency) standards.
Supports 100-240V AC input, adapts to global power grids, and needs to confirm the plug type.
Yes, they suit low-power wearables like heart rate monitors or insulin pumps requiring 5-6V.
Yes, if certified to IEC 60601-1, they ensure safety for pediatric use with low leakage current.
Adapters with IP-rated enclosures can operate in humid conditions; check specifications.
Yes, if the adapter provides 5V via a USB interface compatible with the device’s requirements.
Yes, medical-grade adapters are designed for 24/7 operation with low heat generation.
