ITE Power Adapter UES40-SPA-OP1

ITE Power Adapter UES40-SPA-OP1 Series

12V Board Mount AC DC Converters 40W Switching ITE Open Frame Power Supply

40W

90~ 264 Vac input

-10°C to +55°C temperature range

No-load power consumption < 0.1W

Protections against:short circuit/over current/over voltage

Energy efficiency level VI

Meet 6KV surge immunity

switching dc power supply

DESCRIPTION

The UES40-SPA-OP1 Series is a 40W board-mount 12V AC to DC switching open frame power supply built for compact ITE and embedded systems that need stable output and high safety margins in limited installation space. It supports a wide 90–264Vac input range for global use and operates reliably across a –10°C to +55°C temperature range, making it suitable for both indoor equipment and semi-industrial environments. The design focuses on high conversion efficiency and low energy loss, with no-load power consumption below 0.1W and Energy Efficiency Level VI compliance, helping OEM devices meet modern green power and standby regulations. Integrated protection functions include short circuit, over current, and over voltage protection, combined with 6KV surge immunity to improve durability against grid disturbances and lightning surges. The unit complies with GB4943 safety standards and carries CCC approval, supporting projects that require certified AC-DC power modules for regulated markets. It is widely used in industrial control boards, smart terminals, IoT controllers, medical sub-systems, security electronics, routers, tablets, NAS devices, projectors, barcode scanners, and other compact electronics that require efficient, certified, and surge-resistant open frame power solutions.


Safety&Compliance

Safety Standards – GB4943

Safety Approvals – CCC

Model NumberPower(W)Input Voltage Range(VDC)Output Voltage(VDC)Output Current(A)Operating Temperature Range(℃)Efficiency Standards
UES40-SPA-OP140.090-26412.00.10-3.33-10~+55CE

RELATED APPLICATIONS

The UES40-SPA-OP1 Series is a 40W open-frame AC-DC power supply designed for compact ITE and embedded systems that require stable 12V output and reliable protection. It supports a 90–264 VAC input range, operates from –10°C to +55°C, and meets Level VI energy efficiency with no-load consumption under 0.1 W. Integrated protections include short circuit, overcurrent, overvoltage, and 6 kV surge immunity. Typical applications include industrial control boards, smart terminals, IoT controllers, medical sub-systems, security devices, routers, tablets, NAS devices, projectors, and barcode scanners.

Network Storage (NAS) switching power supply
Network Storage
Tablet computer external power supply
Tablet Computer
Portable Air Purifier switching power supply
portable Air Purifier
ITE power adapter UES140AZ
Projector
wireless router switching power supply
Wireless Routers
barcode scanner external power supply
Barcode Scanners

POPULAR QUESTIONS

This adapter supports output voltage 12V, with a maximum power of 40W.

Yes, it supports USB Power Delivery (PD) protocol.

It's suitable for laptops, tablets, wireless routers, NAS, smart speakers, and other IT equipment.

The maximum output power is 40 watts.

Yes, it includes OCP (Over-Current Protection), OVP (Over-Voltage Protection), and SCP (Short-Circuit Protection).

Yes, DC plug type, USB-C, and cable length can all be customized.

Yes, it supports 100-240V AC input, suitable for worldwide use.

Yes, it  is classified as an ITE adapter.

Operating: 0°C to +40°C; Storage: -20°C to +85°C.
