ITE Power Adapter UEL060LCP-SPA
Home ite-external-power-adapter ITE Power Adapter UEL060LCP-SPA ITE Power Adapter UEL060LCP-SPA 48V 60W LED Driver Power Supply External Switching Wall Mount Power Adapter Wide range of
300 W
90~ 264 Vac input
-20°C to +60°C temperature range
No-load power consumption < 0.5W
Active power factor correction,PF>0.9
Energy efficiency level VI
Fanless design, natural air cooling
Applications： Intelligent service robots, video conferencing equipment, AGV cars, LED stage lights, core switches, electric lift desks
The UES300AZ-SPA is a 300W desktop power supply, positioned as a high-power AC-DC switching external power adapter for home and professional electrical applications. It is designed to deliver stable and continuous power for higher-load ITE systems while maintaining a practical balance between output capability, efficiency, and physical size, making it suitable for both standalone use and integrated system deployment.
This series supports multiple output voltage options, including 19V, 24V, 48V, and 54V, among other configurations, allowing it to flexibly match the electrical requirements of a wide range of ITE devices. With a universal input range of 80–264VAC, it is suitable for global use and can operate reliably across different power grid conditions. Featuring a compact structure, Level VI energy efficiency, and differentiated construction design, the UES300AZ-SPA focuses on reducing energy loss while maintaining dependable high-power output for long-term operation.
In practical applications, these power supplies are widely used in intelligent service robots, video conferencing equipment, AGV cars, LED stage lighting systems, core network switches, and electric lift desks. They provide a stable, efficient, and scalable external power solution for demanding equipment that requires consistent voltage regulation, strong load capability, and reliable performance in both residential and commercial environments.
Safety Standards – GB4943,UL62368,EN62368
Safety Approvals – CCC,cULus,CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES300AZ-SPA | 300.0 | 90-264 | 19.0 | 0.01-15.70 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 20.0 | 0.01-15.00 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 21.0 | 0.01-14.20 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 22.0 | 0.01-13.60 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 23.0 | 0.01-13.00 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 24.0 | 0.01-12.50 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 25.0 | 0.01-12.00 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 26.0 | 0.01-11.50 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 48.0 | 0.01-6.25 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 49.0 | 0.01-6.12 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 50.0 | 0.01-6.00 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 51.0 | 0.01-5.88 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 52.0 | 0.01-5.76 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 53.0 | 0.01-5.66 | -20~+60 | CCC, CE |
| UES300AZ-SPA | 300.0 | 90-264 | 54.0 | 0.01-5.55 | -20~+60 | CCC, CE |
For additional assistance, please complete the form below, and an associate will be in touch with your shortly.
Available options include 19V, 24V, 36V, 48V, and 54V, depending on your application.
The maximum output is 300 watts, suitable for medium to high-power devices.
It's commonly used in robotics, industrial automation, and PoE power systems.
Yes, 48V or 54V versions can power high-power PoE devices like access points and IP cameras.
Yes, both passive and fan-based active cooling options are available based on model.
The input is 100–240V AC, making it compatible with worldwide power standards.
Built-in over-voltage, over-current, over-temperature, and short-circuit protection.
Yes, it complies with DoE Level VI and ErP energy efficiency regulations.
It uses high-temperature resistant ABS+PC material, offering durability and impact resistance.
Yes, DC plug, cable length, and wire gauge can be customized.
