ITE Power Supply UES18LZ-SPA Series
18 W
90~ 264 Vac input
-5°C to +45°C temperature range
No-load power consumption < 0.075 W
Meets Energy efficiency level VI
With different construction for different countries
Meets 6KV surge immunity
DESCRIPTION
The UES18LZ-SPA series is an 18W 12V wall plug ITE switching power supply with a fixed AC pin, certified to the newest 62368 safety standards for all kinds of ITE applications. Featuring compact size, Level VI efficiency(the latest efficiency of DoE Level VI and CoC Tier 2), and good-looking construction, this AC-DC power supply is a continuation of our initiative to provide customers with the most efficient power solutions utilizing the latest in green power technology. These power supplies are used for Wi-Fi routers, Small network switches, IP security cameras, Mini desktop fans, LED strips or controllers, active speakers, and barcode scanners.
Safety&Compliance
Safety Standards – 62368
Safety Approvals – CE/UL/cUL/BSMI/NOM/PSE/KC/RCM/CB
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES18LZ-SPA | 18.0 | 90-264 | 12.0 | 0.01-1.50 | -5~+45 | CB, CE, cULus, EAC, FCC, PSE, RCM |
RELATED APPLICATIONS
POPULAR QUESTIONS
Any 12V device that draws up to 1.5A, such as cameras, routers, LED lights, or small embedded systems.
Yes, it can power up to 18W worth of 12V LED strips. Ensure the total wattage of your LED strip does not exceed the adapter’s capacity.
Yes. It is designed for long-term, stable performance as long as it operates within its rated specifications and has adequate airflow.
It includes over-voltage protection (OVP), over-current protection (OCP), short-circuit protection (SCP), and thermal protection.
Yes. It accepts 100–240V AC input (50/60Hz), suitable for global use with the correct plug type.
The standard output connector is a 5.5mm x 2.1mm DC barrel plug, but this can be customized to match your device.
Most ITE power adapters comply with UL, CE, FCC, RoHS, and energy efficiency standards such as DOE Level VI or ErP.
Not directly. It can supply power to a battery charging circuit, but it is not a dedicated battery charger with CC/CV control.
ITE stands for Information Technology Equipment, which means the adapter is designed and certified for devices like routers, modems, and embedded systems.
Yes. It provides regulated 12V DC output with low ripple and noise, making it safe for sensitive electronic devices.
