Home ite-external-power-adapter ITE Power Adapter UEL060LCP-SPA ITE Power Adapter UEL060LCP-SPA 48V 60W LED Driver Power Supply External Switching Wall Mount Power Adapter Wide range of
180W
90~ 264 Vac input
-0°C to +40°C temperature range
Energy efficiency level VI
No-load power consumption < 0.15W
Protections against:short circuit/over current/over voltage
The UES180AZ-SPA is a 180W universal desktop AC to DC switching power supply, designed as a compact, high-efficiency regulator for ITE and professional electronic devices. Delivering stable 19V and 24V outputs at up to 2.5A, it provides reliable and energy-efficient power for demanding indoor and industrial applications.
Supporting a wide 90–264VAC input range and incorporating GaN technology, this desktop AC-DC adapter meets DOE Level VI efficiency requirements and maintains ≤0.15W no-load standby power for eco-conscious operation. Certified to Energy Efficiency Level VI standards, it integrates robust protections against short circuit, overcurrent, and overvoltage, ensuring safe, dependable, and long-term performance.
With a compact design, Level VI efficiency, and optimized internal construction, these power supplies are widely used for portable displays, industrial control screens, barcode scanning terminal equipment, 3D printers, desktop laser engraving machines, commercial POS equipment, indoor networking devices, and other professional ITE applications. The UES180AZ-SPA provides a versatile, cost-effective, and reliable desktop power solution suitable for OEM integration, replacement adapters, and diverse high-power ITE and industrial electronic applications.
Safety Standards – EN62368
Safety Approvals – CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES180AZ-190YYYSPA | 180.0 | 90-264 | 19.0 | 0.01-9.47 | 0~+40 | CE |
| UES180AZ-240YYYSPA | 180.0 | 90-264 | 24.0 | 0.01-7.50 | 0~+40 | CE |
UES180AZ-SPA is a 180W high-efficiency ITE desktop power adapter for portable displays, industrial control screens, barcode scanning terminals, 3D printers, desktop laser engraving machines, commercial POS equipment, indoor networking devices, and other professional or industrial ITE electronics requiring stable 19V or 24V output.
It comes in fixed 19V or 24V models, suitable for both consumer and industrial devices.
The maximum output power is 180W, with current varying depending on the voltage model.
No, each unit supports a fixed voltage. Dual-voltage models are available upon customization.
19V is ideal for laptops and docking stations; 24V suits PLCs, motor controllers, and LED systems.
The input is 100-240V AC, 50/60Hz, compatible with worldwide power systems.
Yes, it features built-in protections for safe operation.
It is thermally efficient and suitable for long-term continuous use.
Yes, custom lengths and plug types (e.g., 5.52.5mm, 4PIN, XLR) are available.
Yes, it can be certified with CE, FCC, UL, RoHS and is suitable for international markets.
Yes, the 24V version is often used for PoE modules, especially in higher power PoE applications.
