ITE Power Adapter UES12LZ5-SPA
- Home
- ite-external-power-adapter
- ITE Power Adapter UES12LZ5-SPA
ITE Adapter UES12LZ5-SPA
12 W
90~ 264 Vac input
9 ~ 24 Vdc output options
0°C to +45°C temperature range
No-load power consumption < 0.1 W
Energy efficiency level VI
DESCRIPTION
The UES12LZ5-SPA is a 12W ITE AC to DC switching power supply charger, designed with a compact size, Level VI energy efficiency, and differentiated internal construction for stable long-term operation. Supporting a universal 90–264VAC input, this wall plug power adapter delivers regulated 15V and 19V DC output options, meeting DOE Level VI efficiency requirements and maintaining ≤0.075W standby power consumption, making it suitable as a universal AC DC adapter for low-power ITE equipment.
Certified to EN62368,UL62368, and IEC62368, this 12W AC DC power adapter integrates essential electrical protections including short circuit protection, overcurrent protection, and overvoltage protection, ensuring safe and reliable performance for consumer electronics, networking equipment, and compact electronic devices requiring a stable external power supply.
These external switching power supplies are widely used for Wi-Fi routers and access points, desktop phones and VoIP devices, small surveillance devices, LED strips or controllers, media players, portable barcode scanners, and miniature fans. As a cost-effective OEM power adapter and replacement power supply solution, the UES12LZ5-SPA is suitable for indoor networking systems, smart home devices, office automation equipment, and low-power IoT applications requiring efficient and reliable AC-DC wall plug power.
Safety&Compliance
Safety Standards – EN62368,UL62368,IEC62368,
Safety Approvals – CE,UL,CB
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES12LZ5-190YYYSPA | 12.0 | 90-264 | 19.0 | 0.01-0.6 | 0~+45 | CE |
| UES12LZ5-150YYYSPA | 12.0 | 90-264 | 15.0 | 0.01-0.8 | 0~+45 | CE |
RELATED APPLICATIONS
UES12LZ5-SPA is a compact ITE DC plug adapter for Wi-Fi routers and access points, desktop phones and VoIP devices, small surveillance devices, LED strip controllers, media players, portable barcode scanners, miniature fans, and other low-power indoor networking, IoT, and consumer electronics requiring stable 12V regulated output.
POPULAR QUESTIONS
You can power any device that operates on 12V DC and consumes less than 1A (12W), such as routers, small cameras, LED controllers, and VoIP phones.
Yes. As long as the device requires 12V and draws less than 1A, it will only use the power it needs.
It typically includes overvoltage protection, short-circuit protection, overcurrent protection, and thermal shutdown to ensure safe operation.
Most ITE adapters are compliant with international standards like UL, CE, FCC, and meet energy efficiency regulations (e.g., DOE VI, ErP).
It can be used with outdoor-rated cameras, but the adapter itself must be protected from rain or moisture unless it has an IP-rated enclosure.
ITE stands for Information Technology Equipment. These adapters are designed for use with devices like networking gear, office equipment, and embedded systems.
Yes. It supports universal input voltage (typically 100–240V AC, 50/60Hz), making it suitable for use worldwide with the appropriate plug type.
Only if the battery has its own charge management circuit. This adapter provides constant voltage and is not a smart battery charger.
Yes, as long as it operates within its rated limits and has proper ventilation, it’s designed for continuous use.
Commonly it uses a 5.5mm x 2.1mm DC barrel plug. Other types can be customized depending on device requirements.
