ITE Power Adapter UE24-120200SPA-OP2
- Home
- Open Frame ITE Power Supply
- ITE Power Adapter UE24-120200SPA-OP2
ITE Power Adapter UE24-120200SPA-OP2
24W
90~ 264 Vac input
-10°C to +60°C temperature range
No-load power consumption < 0.3W
Protections against:short circuit/over current/over voltage
Meet 2KV surge immunity
Energy efficiency level V
DESCRIPTION
The UE24-120200SPA-OP2 is a 24W PLC built-in AC/DC switching open-frame power supply board engineered for compact embedded power applications where space efficiency, energy saving, and long-term reliability are critical. Featuring an ultra-compact open-frame structure, this internal power board is ideal for system integration inside tightly designed enclosures and control units, especially in OEM and ODM projects that demand stable power delivery with minimal footprint. It supports a universal wide-range AC input of 90–264VAC, making it suitable for global power grids and export-oriented products, while delivering a regulated 12V DC output at 0.01–2.00A to ensure consistent and reliable operation for low- to medium-power electronic systems. With standby power consumption as low as 0.3W max and compliance with IEEE 802.3at/af standards, this high-efficiency AC-DC power module helps reduce overall system energy consumption, improves thermal performance, and supports modern green power and eco-design requirements.
Designed as a cost-effective and stable built-in power solution, the UE24-120200SPA-OP2 combines mature switching power supply topology with robust electrical performance, making it well suited for continuous operation in industrial automation equipment, PLC control systems, aerial photography electronics, security monitoring devices, smart home control units, and portable or mobile handheld electronics. Its open-frame PCB design allows flexible installation and easy integration into customized housings, enabling manufacturers to optimize internal layouts while maintaining electrical safety and reliability. Typical applications include air purifiers, access control card readers, environmental sensor gateway devices, LED light strips, handheld voltage detectors, home gateway devices, IoT terminals, smart sensors, embedded controllers, and low-power communication equipment. With its compact size, universal input, stable 12V output, low standby power, and broad application adaptability, this 24W open-frame AC/DC power supply board is an ideal choice for manufacturers seeking an efficient, economical, and scalable internal power module for industrial, smart home, and IoT applications.
Safety&Compliance
Safety Standards – IEC62368,GB4943
Safety Approvals – CB,CQC
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UE24-120200SPA-OP2 | 24.0 | 90-264 | 12.0 | 0.01-2.00 | -10~+60 | CE |
RELATED APPLICATIONS
The UE24-120200SPA-OP2 is a 24W 12V open-frame AC/DC power supply board with 90–264VAC input, low standby power (≤0.3W), and a compact PCB design for embedded integration. It provides stable 0.01–2.0A output for PLC systems and space-limited equipment, and is commonly used in industrial controllers, access control readers, air purifiers, LED strips, IoT gateways, smart sensors, handheld devices, and other low-to-medium power embedded electronics.
POPULAR QUESTIONS
It supports a wide input voltage range of 90–264VAC.
Yes, it provides a stable constant 12V output.
The maximum output current is 2A.
Yes, it includes auto-recovery overload protection.
Yes, it enters protection mode during short circuit.
Suitable for routers, sensors, control boards, LED drivers, etc.
Natural convection is typically sufficient, no fan needed.
Most models have no minimum load requirement.
Some models support ±10% voltage trimming.
Yes, with built-in EMI filter to meet industrial standards.
