ITE Power Adapter UEL060LCP-SPA
Home ite-external-power-adapter ITE Power Adapter UEL060LCP-SPA ITE Power Adapter UEL060LCP-SPA 48V 60W LED Driver Power Supply External Switching Wall Mount Power Adapter Wide range of
Wide range of AC input voltage 90- 264VAC
Protections against: short circuit/over current
IP20 design for indoor application
Nonconstant current function
Meets ERP(EU)2019/2020 energy efficiency standard
Changeable AC plugs for universal use
Output match DC Jack/DC Cable
Fireproof plastic housing
The UE020LCP and UE020LCP1 are practical 20W constant voltage LED driver power supply units engineered as reliable external power solutions for information technology and general ITE environments. This compact SMPS LED driver adopts an IP20 mechanical design that fits easily into indoor equipment and modern lighting systems.
With a universal AC input voltage range from 90 to 264VAC, the adapter operates stably under different grid conditions and avoids additional transformer requirements.
The regulated output covers 9VDC, 12VDC, 15VDC, 19VDC, 24VDC versions with output current up to 1.5A, providing flexible power margin for OEM projects and custom power adapter applications. Built-in short circuit protection and intelligent over current protection keep LED modules, panel lights, ceiling lights, monitors, routers, and other information technology equipment safe during abnormal load or installation mistakes. The hardware design focuses on low ripple noise, good load regulation, and long service life, reducing maintenance cycles for system integrators.
Fully meeting ERP EU 2019/2020 energy efficiency requirements, this energy saving power supply supports low standby consumption and high efficiency operation for long-term deployment. It works effectively in versatile networking and lighting scenarios including table lamps, ceiling lights, panel lights, hallway fixtures, office lighting, home appliance control boards, POS devices, printers, and communication equipment, giving engineers a cost-effective external power supply that can pass global safety compliance such as CCC, cULus, CE, and EN62368-1 related standards without redesign risk.
Safety Approvals – CCC,CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UE020LCP/UE020LCP1 | 20.0 | 90-264 | 9.0 | 0-2.00 | 0~+40 | CCC |
| UE020LCP/UE020LCP1 | 20.0 | 90-264 | 10.0-12.0 | 0-1.50 | 0~+40 | CCC |
| UE020LCP/UE020LCP1 | 20.0 | 90-264 | 13.0-15.0 | 0-1.30 | 0~+40 | CCC |
| UE020LCP/UE020LCP1 | 20.0 | 90-264 | 18.0-24.0 | 0-0.83 | 0~+40 | CCC |
UE020LCP / UE020LCP1 are 20W ITE LED driver power supplies for Advertising Sign Lights, Ceiling Lights, Decorative Lighting, Floor Lamps, LED Strips, Table Lamps, as well as monitors, routers, POS devices, printers, and other IT equipment, providing stable constant voltage, low ripple, and reliable protection for indoor lighting and general ITE applications.
An LED driver is a power supply device specifically designed to provide constant current or constant voltage to LED lights, ensuring stable operation, preventing flickering and overheating, and extending their lifespan.
An LED driver provides constant current or constant voltage output and has overcurrent, overvoltage, and short-circuit protection. Regular adapters mostly provide constant voltage output, which may cause LED flickering or shorten their lifespan..
Common types include constant current (CC) and constant voltage (CV), as well as adjustable and non-dimmable types. The appropriate type must be matched to the type of lighting fixture.
Constant current (CC): Outputs a fixed current, suitable for LED lights connected in series, such as high-power lighting fixtures or LED strip lights.
Constant voltage (CV): Outputs a fixed voltage, suitable for lighting fixtures or LED strip lights connected in parallel.
The driver power should be about 10-20% higher than the total power of the LED lights to ensure margin and stability. For example, a 24W lamp can be paired with a 30W LED driver.
Some LED drivers support dimming, including 0-10V, PWM, and Triac dimming. The lamp itself must be compatible with dimming functionality; otherwise, it may flicker or be damaged.
High-quality LED drivers can have a lifespan of over 50,000 hours. Ambient temperature and heat dissipation conditions will affect lifespan.
LEDs not lighting up, flickering, or unstable brightness; abnormal driver overheating. Common causes include overcurrent, overvoltage, or circuit faults.
Yes, but you need to confirm that the light fixture supports an external driver and that the output parameters match. Some ceiling lights have built-in drivers, which may not be compatible with external drivers.
Yes, but you need to ensure that the output voltage, current, dimming compatibility, and protection rating match; otherwise, you may damage the LED light.
